1. Operating environment: Tool dedicated software (version 4.1), with simulation operation software.

2.Display screen description: 17-inch LCD screen, which displays mechanical coordinates, relative coordinates, absolute coordinates and execution processing on the screen A dialog framework for operations such as setting.

3.Interface description: The operation of the tool processing software (Version 4.1) includes diameter, number of threads (number of slots), and screw Degree, slot length, slot speed, slot depth (slot depth increment adjustment), spiral direction (left rotation, right rotation).

4.Keyboard: Thin film button keyboard, letters and numbers are connected to the display.

5.Hard disk: 256G

6.Control system: Taiwan SYNTEC.

7.Data input and output mode == keyboard input, computer connection.

8.Simulation: 2D simulation, 3D simulation, 3D collision check, the shape of the processed material can be seen, and the parameters can be modified according to the parameters obtained after simulation.

9.Software package functions:

10.The latest version is used, leaving room for upgrade.
